Universal Exposed Floor Standing Fan Coil Unit for Chilled / Hot Water
Time : Apr 25 2026
Universal Exposed Floor Standing Fan Coil Unit for Chilled / Hot Water

Product Description

Universal-Exposed-Floor-Standing-Fan-Coil-Unit-for-Chilled-Hot-Water
Universal-Exposed-Floor-Standing-Fan-Coil-Unit-for-Chilled-Hot-Water
Universal-Exposed-Floor-Standing-Fan-Coil-Unit-for-Chilled-Hot-Water
Fan coil design condition:
1.Cooling capacity as following.
  1)Water temperature: 7 C( inlet )/12C ( outlet) or customized
  2)Air entering condition: 27 C DB/19.5C WB or customized
2.Heating Capacity as following(with same water flow rate as cooling cycle):
  1)water temperature: 60C( inlet) or customized
  2)Air entering condition: 21C DB or customized
3.The air volume is tested under entering air condition of 20 C DB and dry coil condition.
4.The sound pressure level is based on 11.5d B(A)anechoic room background noise.
5.The manufacturer reserves the rights to make changes to the above specification without notice.

Universal-Exposed-Floor-Standing-Fan-Coil-Unit-for-Chilled-Hot-Water


Universal-Exposed-Floor-Standing-Fan-Coil-Unit-for-Chilled-Hot-Water
Product Parameters
Model                      FCU34516885102136170204238
Air flowHm3/h34051068085010201360170020402380
Mm3/h2553835106387651020127515301785
Lm3/h17025534042551068085010201190
Total cooling capacity *HW18002700360045005400720090001080012600
MW1440216028803600432057607200864010080
LW117017552340292535104680585070208190
Sensible cooling capacity*Hm3/h1307196126153268392252296537784410300
Mm3/h117717652353294235304706588370608500
Lm3/h105915882118264731774236529563547460
Heating capacity*HW2700405054006750810010800135001620018900
MW216032404320540064808640108001296015120
LW18572633351043885265702087751053011340
Standard external pressurePa121212121212121212
Power input12PaW35.24657.46986123160189228
30PaW39.55566.982100136175211247
50PaW49.55985.493108155188236297
Sound pressure Level**12PadB(A)373941434546485052
30PadB(A)404244464748505254
50PadB(A)424446474950525456
Net weightkg10.514.61616.518.523.525.530.535.5
Water flow ratem3/h0.40.510.710.921.051.41.752.12.5
Water pressure dropkPa202025303540404550
Water connectionsInchRC 3/4
Drain pipeInchRC 3/4
Fan motor quantityNr.111112222
Fan quantityNr.122223444
Max. working pressureMpa2
Power supply/220V/1Ph/50Hz
Universal-Exposed-Floor-Standing-Fan-Coil-Unit-for-Chilled-Hot-Water

Universal-Exposed-Floor-Standing-Fan-Coil-Unit-for-Chilled-Hot-Water

Universal-Exposed-Floor-Standing-Fan-Coil-Unit-for-Chilled-Hot-Water
