Steam Heating Air Curtain
The ST series steam heating air curtain is a high-efficiency, large-heat-output air barrier equipment, which uses industrial steam (saturated steam) as the heat source. It integrates steam heat exchange and air supply functions, forming a dense and warm air curtain at the doorway to effectively isolate indoor and outdoor cold-hot air exchange, quickly supplement indoor heat, prevent dust, insects and harmful gases from entering, and reduce energy consumption. It is widely used in industrial workshops, large commercial venues, hospitals, and other places equipped with a central steam supply system.
Email：zkeruiteair@gmail.com
WhatsApp：+8613105346663
product description
1. Product Overview
ST Series Steam Heating Air
Curtain
The ST series steam heating air curtain is
a high-efficiency, large-heat-output air barrier equipment, which uses industrial steam (saturated steam) as the
heat source. It integrates steam heat exchange and air supply functions, forming a dense and warm air curtain at
the doorway to effectively isolate indoor and outdoor cold-hot air exchange, quickly supplement indoor heat,
prevent dust, insects and harmful gases from entering, and reduce energy consumption. It is widely used in
industrial workshops, large commercial venues, hospitals, and other places equipped with a central steam supply
system.
Core Features
- Heat Source: Suitable for saturated steam supply systems (recommended steam pressure: 0.3-0.6MPa; steam temperature: 130-160℃)
- Heat Exchange System: High-efficiency stainless steel steam heat exchanger, corrosion-resistant, high heat transfer efficiency, fast temperature rise, and strong heat retention
- Air Supply Performance: Cross-flow fan design, uniform airflow, large air volume, dense air curtain, strong isolation effect, no obvious wind sense
- Control Mode: 2-speed / 3-speed mechanical switch or intelligent PLC control, optional linkage with steam valve and central control system for automatic temperature regulation
- Installation Type: Top-mounted (ceiling/door lintel), suitable for large doorways; customized installation solutions available for special scenarios
- Safety Protection: Equipped with overheat protection, pressure relief valve, and anti-dry burning device, ensuring safe and stable operation; steam condensate recovery design, energy-saving and environmentally friendly
- Casing Material: High-quality thickened aluminum alloy + stainless steel, anti-corrosion, anti-oxidation, durable, suitable for harsh industrial environments; standard color: gray, custom colors available
- Certifications: CE, CCC, ISO9001, compliant with international industrial safety and quality standards, suitable for global export markets
Application Scenarios
Large industrial workshops, factories,
shopping malls, supermarkets, hotels, hospitals, railway stations, and other places with door width ≤ 4m, door
height ≤ 4.5m, and central steam supply system. Especially suitable for cold regions, high-temperature
workshops, and places that require rapid heating and strong air isolation.
2. Selection Parameter Table (ST Series Steam Heating Air Curtain)
3. Key Selection Notes
- Model Interpretation: ST = Steam Heating Series; 12/15 = Impeller Diameter (120mm / 150mm); 12/15/18/20 = Body Length (1200/1500/1800/2000mm); T = Top-mounted (Standard); D = Heavy-duty (Large Air Volume & Steam Consumption)
- Steam Requirement: The recommended steam pressure is 0.3-0.6MPa, and the steam temperature is 130-160℃. It is recommended to install a steam filter and pressure regulating valve at the inlet to ensure stable steam supply and prevent pipeline blockage.
- Selection Principle: The body length should be 10-20cm longer than the door width; for door height ≤ 3m, choose 12 series; for door height 3-4.5m, choose 15 series heavy-duty model; for places with large temperature difference or high heat demand, prioritize models with large steam consumption and heat exchange area.
- Safety & Maintenance: Regularly check the steam pipeline, heat exchanger, and pressure relief valve to ensure no steam leakage; clean the heat exchanger and filter screen regularly to maintain heat exchange efficiency; drain the internal condensate in winter when not in use to prevent freezing and cracking of the heat exchanger.
- Double Values Explanation: All double values in the parameter table (Motor Power, Air Volume, Air Speed) correspond to High / Low speed respectively; steam consumption is a range, adjustable according to actual steam pressure and heating demand.
4. Full English Product Description
ST Series Steam Heating Air Curtain is a
high-performance air barrier equipment designed for industrial and large commercial places equipped with a
central steam supply system. It takes saturated steam as the core heat source, cooperates with a high-efficiency
stainless steel heat exchanger and cross-flow fan, forming a dense and warm air curtain at the doorway, which
can effectively isolate indoor and outdoor air convection, quickly supplement indoor heat, and reduce energy
loss caused by heat exchange.
With excellent heat transfer performance,
the ST series can quickly heat the passing air, realizing rapid temperature rise at the doorway and improving
indoor thermal comfort. The thickened aluminum alloy and stainless steel casing is corrosion-resistant and
anti-oxidation, which can adapt to harsh industrial environments and ensure long-term stable operation. The
intelligent control system (optional) can be linked with the steam valve and central control system to realize
automatic temperature regulation and steam flow control, saving manpower and energy.
Equipped with complete safety protection
devices (overheat protection, pressure relief valve, anti-dry burning), the product ensures safe operation in
high-pressure steam environments. Certified by CE, CCC, ISO9001 and other international standards, the ST series
steam heating air curtain meets the quality and safety requirements of global industrial and commercial markets,
providing an efficient, energy-saving and safe air barrier solution for large-scale venues and industrial
workshops.
