Model Description:

"TMU" : Marine air conditioner

J: indicates sterilization

35: Nominal cooling capacity is 35kW

X: mute the sound

Main components:

Mainly by mixing tank, sterilization equipment, air filter with frequency conversion motor, centrifugal fan, ships, air cooler, air heater, dry steam humidifier, water retaining, silencer, water plate, static pressure box, the wind out refrigerant piping, steam piping, electrical control cabinet (including frequency converter) and control components, etc. All components are mounted on a common chassis.

Product features:

Deadened the noise of Marine sterilization inverter working principle of combined air conditioning device is the low frequency noise fan according to the working condition of demand under the suitable frequency operation to drive the air flow, outside fresh air and withdraw the air chamber under the stepless drive air brake control in proportion into the air conditioner, after sterilization mixed period of sterilization in addition to the peculiar smell, first through the air filter to remove large particles of dust, After the surface cooler is absorbed heat to cool and dehumidify, its temperature is accurately controlled through the three-way valve proportional regulation of refrigerant water flow, and then through the muffler section for equalized flow noise reduction processing, and finally through the hydrostatic box after secondary noise reduction into each cabin.

Product advantages:

Marine sterilized and silenced frequency conversion combined air conditioning unit integrates all functional components into one, which has the advantages of simple operation, compact structure, stable performance, low energy consumption, low noise, sterilization and disinfection, anti-impact and swing, and convenient maintenance. Air conditioning units are designed, manufactured and delivered according to classification society specifications and standards (such as "CCS", "ABS", "NK", "DNV", etc.), and can be customized according to the actual needs of customers.

基本参数：

Cooling capacity: 23KW-350kW

Heating capacity: 35KW-350kW

Air ?ow:2200-30000m/h3

Air pressure: 500-2000Pa
